KAN-D Series
KAN-D240
- Dimensions
- 45x131x132 mm
- Power
- 240 W
- Input voltage
- 220(80...264) VAC
- Output voltage
-
15 VDC
24 VDC
- Efficiency
- 90-92%
- Warranty
- 2 years
- Operation temperature
-
-25...+70 °C
-50...+70 °C
Key Features:
- Power 150 W
- input voltage from 80 to 264 VAC (112...372 VDC)
- output voltage 12; 24; 48 V with efficiency 92-93% and output current up to 30A
KAN-D240 model range
Show all
| Title | Power | Input Voltage | Output | Dimensions | Work. Temp. | Status |
|---|---|---|---|---|---|---|
| KAN-D240C15N | 240 | 220(80...264) VAC | 15 VDC | 45х131х132 mm | -25...+70 °C | Series |
| KAN-D240C24N | 240 | 220(80...264) VAC | 24 VDC | 45х131х132 mm | -25...+70 °C | Series |
| KAN-D240C24P | 240 | 220(80...264) VAC | 24 VDC | 45х131х132 mm | -50...+70 °C | Series |
